The rated capacity varies widely from 30Tons to 100Tons, and the dimension different from 7000mm to 18000mm, we can manufacture it according to your needs.
The side wall height and side or back door numbers and opening ways have several options for your better usage.
Specification of dry van trailer:
| Dimension | 13000mm*2500mm*4000mm |
| Load Capacity(T) | 40T |
| Axle | 2 axles |
| Tire | 8 units |
| Suspension | Mechanical suspension |
| King pin | brand 2.0 or 3.5inch(bolted or welded type) |
| Support leg | brand |
| Main beam | Height: 500mm Upper Plate: 14mm Middle Plate: 8mm
Bottom Plate is 16mm; Material: Q345B Steel |
| Side beam | 16mm or 18mm steel channel(Material: Q235steel) |
| Brake chamber | WABCO |
| ABS | Optional |
| Valve | WABCO valve |
| Light | LED light (specially intended for oversea market) |
| Voltage | 24V |
| Receptacle | 7-pin Socket (for 7 wire harness) |
| Semi Trailer
Surface Coating |
Sandblasted, anti-rust chassis surface is available with 1layer of anticorrosive primer and 2 layers of top coats |
